MINI AHD Weatherproof IP67 Car Black Box Camera With IR RCDP5

Description:

This is a high quality Color Waterproof Camera designed for PAL systems. Using the latest CCD technology, the camera can produce high resolution with little distortion. The camera has a wide operation temperature range and is not subject to distortion from magnetic field. With its lightweight and compact size, this camera can be used for monitoring and surveillance.

Packing list:

Camera 1

Instruction Manual 1

Camera Bracket 1

Self Drilling Screw 3

Mounting Plug 3

Option Lens selectable from f2.5mm to f12mm

Operation procedures:

1. Loosen the lock screws (3)

2. Attach the mounting base (1) to the wall or ceiling, wherever you want to install the camera. Locate a wall stud or ceiling joint and secure the base by the supplied mounting screws.

3. Connect the 4 ways male din jack to the female jack on the cable, when picture shown up on the monitor.

4. Make the ball camera (2) to the suitable position.

5. Fix the ball camera, then lock the screw (3).

L model dimension figure:

Connection:

Remark:

When mirror loop was cut, camera change to Mirror picture.

Specifications:
